Description
| Machine model | SM1325 cnc plasma cutting machine |
| Working area | 1300*2500mm |
| Plasma Generator |
100A (60A 120A 160A 200A optional)
|
| Working mode | Untouched Arc Striking Arc Pressure Adjuster |
| Control system | Start control with Automatic torch height control |
| Interface | USB port |
| Cutting thickness | 0-30mm according to generator power |
| Cutting speed | 0-8m/min |
| Moving speed | 0-50m/min |
| Lubrication system | Yes |
| Automatic height adjust | Yes |
| Machine structure | thick steel tube welding |
| Rail type | Taiwan square linear rails |
| Drive type | Stepper |
| Transmit | gear rack |
| Voltage | AC380V±10%, 50-60Hz |
| Application | Metal: iron, steel, carbon steel, stainless steel, etc. |
| Machine/packing size | 3*2.06*1.4m/3.15*2.21*1.61m |
| Net/Gross weight | 800kg/1000kg |
